Basket Strainer / Y-Strainer

The Glass Ceramic Matrix Composite is the novel material and the reason this cell earns a place: the vendor markets it for combined corrosion AND abrasion, explicitly naming seawater and scrubber systems — most materials in this project's rules address one property or the other. The FRP 5-layer laminate schedule is unusually specific vendor engineering disclosure and makes excellent open reference content. Real selection distinction: the FRP series uses FRP as the primary chemical barrier while GS Series uses a thermoplastic liner with fiberglass only for structural strength — two different answers to the same problem. Duplex configurations give continuous uninterrupted operation, the requirement in any recirculating aquatic or scrubber loop. Materials to confirm: Glass Ceramic Matrix Composite (fiberglass + ceramic + vinyl ester), Basket material options: 316 Stainless, AL6XN, CPVC, Hastelloy, Monel, PP, PVC, PVDF, Titanium, Flowline chart: sea water rates E across PVC/PP/PVDF/PFA/PTFE/316SS, but saturated salt water drops 316SS to F at both 40°C and 80°C. Specific chemicals include sea water, salt water, potable water, pool and aquarium recirculation water, scrubber liquor.

Send LibertyCES your fluid, chemistry, concentration, temperature, flow, pressure, and suction conditions for a free spec review of Basket Strainer / Y-Strainer against your actual process data — not a generic catalog match.
